New aviation publication

New publication to hit the stands in early February.

The first edition of the new "NZ AeroNews" edited by Graeme Porter will hit the stands from February 1st 2008.

It will be in a similar but updated format to NZ Aviation News which Graeme has been involved with for the last 15 years.

Due to irreconsilable differences with the other two shareholders Graeme has gone his seperate way.

All the current contributors and a very high percentage of the advertisers have moved to the new publication.

Is this the end of NZ Aviation News ?


Noted at Christchurch 24.12.07 MD500E ZK-INM which was until recently ZK-HOT with Alpine Helicopters in Wanaka.

Passing through.

Strong Northeasterly winds restricted the lighter side of aviation around Christchurch this weekend.

However I did catch the Dyn Aero MCR01 Club ZK-WIK c/n 342 as it arrived at Rangiora direct from Parakai in under four hours.

After a quick refuel and toilet stop it headed off to Balclutha.

Question time

Thought I would throw in an occasional question.

Question being :-

What is it ?

And once you have that:-

What is its registration ?

Glider and pilot lost.

I can now confirm that the glider which crashed whilst competing in the GP gliding Competition was the Schleicher prototype ASG29 D-2929 c/n 29001 with pilot Herbert Weiss.

Photo from the Alexander Schleicher web page.

On behalf of this site I extend our sympathy to Herbert's family.

Tradgedy at the GP Gliding today.

News has just broken that an overseas glider pilot was killed today participing in the GP Gliding event out of Omarama.
The glider failed to complete the course and the wreck was found late this evening, I believe near the top of Lake Wanaka.
Only one glider failed to feature on the days score board, so I think it a fair guess that it was this particular machine. An ASG29.


I've just discovered that if you click on the subject heading, then the comments come up on the same screen.

Easier than clicking on the "Comment" at the bottom of the post and getting another slow loading overlay.

I'm slowly learning !

I noted the olde DC-3 overflying the Garden City at about 1530 this afternoon. Looked like "Amy".
It certainly had two engines and both were circulating.

ZK-JSN dyselxic Jetstream on FAA site.

Just finally managed to get into the FAA web site and:-

N135KM "is not assigned/reserved"

N153KM is listed as Jetstream 4101 c/n 41053 with a cert date of 12-01-2007 (that far back) to Northstar Aviation LLC of Boca Raton, Florida.

ZK-JSN Confirmation

Well it's certainly marked up as N135KM, as can be seen. They could of course have made mistake in painting it on. Thanks for enlightening me on the rationale.

Jetstream ZK-JSN

Can somebody confirm that JSN has in fact become N135KM ?

The others seem to have used the last two numbers of their c/ns as the last two in their "N" number.

In other words, I am expecting it to become N153KM !

AW139 Flies Away!

Helicopters (NZ) latest flagship, AW139 ZK-HNZ, flew away from Ardmore this morning following its reconstruction with Hawker Pacific. The helicopter departed to the west and appeared on radar to continue south so presume it has been delivered to New Plymouth.

On departure from Ardmore, Colin Hunter photo

Jetstream J41's Change Identity

The last two former Origin Pacific Jetstream 41's have gone onto the US Civil Register. Between 12th and 14th December, the former ZK-JSO became N156KM, and ZK-JSN became N135KM. The former looks ready to go, while N135KM probably has some time here yet.

Just to see what happens when I upload some more photographs! The R44 is ZK-HFF at North Shore on 12th, and the Saratoga N515SC was there at the same time.

Trust the computers are still intact after that!

8000th Robinson

Robinson R44 II ZK-HGZ S/N:11984 seen outside Skysales Christchurch facility 19.12.07 has the distinction of being the 8000th Robinson helicopter produced. HGZ will be delivered to it's new owner by weeks end.

Northland Note

Just a trial really - to see whether I can master this new technology! Wandered around parts north of Auckland last week. At North Shore on 12th, assembly of new R44 HFF was almost finished - all-over dark blue. HeliNorth tell me it will be partially repainted on delivery (the previous HFF, an R22, still exists more or less intact outside their hangar at Whangarei). They are operating R44's HPS and IMH at present. Being assembled at Whangarei Airport was R44 II HGM for Salt Air (a 2-3 year old ex-US machine N442RB with 120 hours up). It will join B206 HFE. At Kerikeri Airport, recent import Cessna 172 TRS was noted in company with similar machine WAX. TRS's predecessor TAR also seemed to be frequently coupled to WAX! At Heliops base, R44's HXA and HXC were outside with a 'new' R22B in the hangar for Croydon Thompson.

System test only

Photo attached as test only to check system.
Picture taken at Wanaka 16-08-2006.

Rangiora Sunday 16th December

A brief visit to Rangiora found the recently imported Solar Wings Pegasus XL-R ZK-JSJ/2. It still also wears its UK registration of G-MTIV. Its c/n is SW-WA-1195.

I note that the time expired Zlin has gone from its hangar and the damaged fuselage that was decaying outside has also moved on. Gone south says a local. (Taieri ?).

There is a heap of damaged parts still lurking in the corner.

And yes it really does fly. The Ragwing Pietenpol Exp ZK-RWA of a Wayne Wilson on final.
Piper PA46 Malibu N9099Z still plies the airways in its US marks.

The old Auster J4 ZK-AXC c/n 2080 owned by Byron Kelly has taken the Zlins place in the Hangar. Looks rather dashing with its Lycoming engine and clear door panels and big boots.

The Hughes 369D ZK-HXZ/2 c/n 117-0233D of Amuri Helicopters appears to be in a new scheme

Christchurch Sunday 16th Dec

A quick drive past Christchurch found Raven 11 ZK-HKJ/3, c/n 10757, had just landed outside its hangar on the western side of the field. The owner William Johnstone's previously operated the Cessna A185 F ZK-WHJ, c/n 18504304.

Purely by chance this very Skywagon was parked across two fences on the western grass wearing its Glacier Skydive Air Services Ltd scheme. If memory serves me right, this is a meat bomber out of Fox Glacier.


Hi Dave,

Great to see ta Blog dedicated to the lighter ZK- stuff, and nice to see Skysales featured! The R44 HGI/DJ also carried HLD marks first but was changed the day of CofA.
EC-120 IFR flew yesterday and will have CofA on Tuesday, we will be flying ITT & HGZ Thu/Fri
Attached some shots from a work trip upto Gisborne last Friday. The Alouette is Ex ZK-HYA.

Best Regards


More Christchurch helicopters

Skysales Christchurch on 11-12-2007.

One 40ft container spews out three large crates as above.
The white one is Raven 11 c/n 11983 and is now ZK-ITT.
Green one, another Raven 11 is c/n 11984 and ZK-HGZ/4.
In the rear crate is the black with silver striped Raven 11 c/n 11990 to be ZK-HTF/5.

Recent Christchurch Helicopter sightings.

Same helicopter, different days.
This Robinson R44 Raven 11 c/n 11972 was registered as ZK-HGI/3 on 06-12-2007 as seen above at Skysales Christchurch on 07-12-07.
It was also cancelled on the 7th and was re-registered as ZK-HDJ/4 as seen below photographed on the 14th.


A pilot must be able to accurately and rapidly solve any problems that involve the shift, addition, or removal of weight. For example, the pilot may load the aircraft within the allowable takeoff weight limit, then find a CG limit has been exceeded. The most satisfactory solution to this problem is to shift baggage, passengers, or both. The pilot should be able to determine the minimum load shift needed to make the aircraft safe for flight. Pilots should be able to determine if shifting a load to a new location will correct an out-of-limit condition. There are some standardized calculations that can help make these determinations.

When weight is shifted from one location to another, the total weight of the aircraft is unchanged. The total moments, however, do change in relation and proportion to the direction and distance the weight is moved.

When weight is moved forward, the total moments decrease; when weight is moved aft, total moments increase. The moment change is proportional to the amount of weight moved. Since many aircraft have forward and aft baggage compartments, weight may be shifted from one to the other to change the CG. If starting with a known aircraft weight, CG, and total moments, calculate the new CG (after the weight shift) by dividing the new total moments by the total aircraft weight.

To determine the new total moments, find out how many moments are gained or lost when the weight is shifted. Assume that 100 pounds has been shifted from station 30 to station 150. This movement increases the total moments of the aircraft by 12,000 lb-in.

Moment when at station 150 = 100 lb x 150 in = 15,000 lb-in
Moment when at station 30 = 100 lb x 30 in = 3,000 lb-in
Moment change = 12,000 lb-in

By adding the moment change to the original moment (or subtracting if the weight has been moved forward instead of aft), the new total moments are obtained. Then determine the new CG by dividing the new moments by the total weight:

Total moments = 616,000 + 12,000 = 628,000

The shift has caused the CG to shift to station 78.5

A simpler solution may be obtained by using a computer or calculator and a proportional formula. This can be done because the CG will shift a distance that is proportional to the distance the weight is shifted.

Weight Shifted = CG (change of CG)
Total Weight Distance weight is shifted 100 = CG 8,000
120  CG = 1.5 in

The change of CG is added to (or subtracted from when appropriate) the original CG to determine the new CG: 77 + 1.5 = 78.5 inches aft of datum The shifting weight proportion formula can also be used to determine how much weight must be shifted to achieve a particular shift of the CG. The following problem illustrates a solution of this type.

Aircraft Total Weight . . . . . . . . . . . . . . . . .7,800 lb
CG . . . . . . . . . . . . . . . . . . . . . . . . . . . .Station 81.5
Aft CG Limit . . . . . . . . . . . . . . . . . . . . . . . . . .80.5

Determine how much cargo must be shifted from the aft cargo compartment at station 150 to the forward cargo compartment at station 30 to move the CG to exactly the aft limit.

Weight to be Shifted = �CG
Total Weight Distance weight is shifted
Weight to be Shifted = 1.0 in
7,800 120 in
Weight to be Shifted = 65 lb


Another method for determining the loaded weight and CG is the use of graphs provided by the manufacturers.

To simplify calculations, 100, 1,000, or 10,000 may sometimes divide the moment. The following is an example of the graph method.

Front Seat Occupants . . . . . . . . . . . . . . . . . . 340 lb
Rear Seat Occupants . . . . . . . . . . . . . . . . . . 300 lb
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 gal
Baggage Area 1 . . . . . . . . . . . . . . . . . . . . . . . 20 lb

The same steps should be followed as in the computational method except the graphs provided will calculate the moments and allow the pilot to determine if the airplane is loaded within limits. To determine the moment using the loading graph, find the weight and draw a line straight across until it intercepts the item for which the moment is to be calculated. Then draws a line straight down to determine the moment. (The red line on the loading graph represents the moment for the pilot and front passenger. All other moments were determined in the same way.) Once this has been done for each item, total the weight and moments and draw a line for both weight and moment on the center-of-gravity envelope graph. If the lines intersect within the envelope, the airplane is loaded within limits. In this sample-loading problem, the airplane is loaded within limits.

More Wigram sightings

On Tuesday the 11th I found the Avid Mark IV ZK-JHW c/n 1434D tucked away in the hangar.

This is a recent arrival for Grant Porter and is ex Kaitaia Aero Club.

Interestingly this Avid whilst under the ownership of Paul Havill flew out to the Chatham Islands accompanied by the Sky Arrow 480T ZK-EBR/2 back on 09-04 2004.

Parked out on the grass was the Cessna T182RD ZK-MAS/2 c/n 182RG0061 of Morpheus Aviation from up Hamilton way.

Others aircraft noted were the 150hp Cessna A150L ZK-CZZ/2, c/n 1500447 out for its pre summer wash down.

Piper PA31-325 Navajo ZK-NOW/2 c/n 31-7912032. Its ownership changed to Brick Securities Ltd with an Auckland address on 22-11-2007.

One aircraft missing (not the DC-3 - which is in WN minus an engine) but the Piper PA60 Aerostar 600 belonging to Clive Ridge. This was ex VH-UYU and has aspirations of becoming ZK-TSA. This arrived in May 2001 and has been parked in the rear corner of the hangar pretty much ever since. It has been in bare metal - all paint removed and the engines inhibited for yonks.

Devon ZK-XNZ flew in about a week ago and appears to be on a maintenance check (cowls off). It was last noted at Ashburton in the rear of the hangar minus props.

Trial photo insertion & belated Wigram note.

A quick visit to Wigram on Monday the 10th of December found Super Air FU24A-954 c/n 278 just starting up to depart back north. This dual control Fletcher has been at Gore with Phoenix Aviation pilot training.

If I have got the system sorted & this message appears ok, then I will add more pics during the weekend.

Recent Additions

Spied at Ardmore today, 13Dec07, where two recent additions to the ZK register. Peter Vela of NZ Bloodstock has added Eurocopter EC130 ZK-HPV (4322) to his stable bringing the NZ population of these machines to one dozen. This is the third helicopter to wear this personalised registration and joins Eurocopter AS350B3 ZK-IPV. ZK-HPV/3 was placed on the register just three days ago.

Lifting for circuits, Mike Condon photo

On the lighter side of helicopters was Ardmore Helicopters latest addition, Schweizer 269C-1 ZK-IMX (0316). It was parked outside the Oceania facility. It was only registered two days ago.

Mike Condon photo


There are various methods for determining the loaded weight and center of gravity of an aircraft. There is the computation method, as well as methods that utilize graphs and tables provided by the aircraft manufacturer.

The computational method involves the application of basic math functions. The following is an example of the computational method.

Maximum Gross Weight . . . . . . . . . . . . . . 3400 lb
Center-of-Gravity Range . . . . . . . . . . . . . 78-86 in
Front Seat Occupants . . . . . . . . . . . . . . . . . . 340 lb
Rear Seat Occupants . . . . . . . . . . . . . . . . . . 350 lb
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 gal
Baggage Area 1 . . . . . . . . . . . . . . . . . . . . . . . 80 lb

To determine the loaded weight and CG, follow these steps.
Step 1—List the weight of the airplane, occupants, fuel, and baggage. Remember that fuel weighs 6 pounds per gallon.
Step 2—Enter the moment for each item listed. Remember "weight x arm = moment."
Step 3—Total the weight and moments.
Step 4—To determine the CG, divides the total moment by the total weight.

NOTE: The weight and balance records for a particular airplane will provide the empty weight and moment as well as the information on the arm distance.

The total loaded weight of 3,320 pounds does not exceed the maximum gross weight of 3,400 pounds and the CG of 84.8 is within the 78-86 inch range; therefore, the airplane is loaded within limits.


The airplane's weight and balance restrictions should be closely followed. The loading conditions and empty weight of a particular airplane may differ from that found in the AFM/POH because modifications or equipment changes may have been made. Sample loading problems in the AFM/POH are intended for guidance only; therefore, each airplane must be treated separately. Although an airplane is certified for a specified maximum gross takeoff weight, it will not safely take off with this load under all conditions.

Conditions that affect takeoff and climb performance such as high elevations, high temperatures, and high humidity (high-density altitudes) may require a reduction in weight before flight is attempted. Other factors to consider prior to takeoff are runway length, runway surface, runway slope, surface wind, and the presence of obstacles. These factors may require a reduction in weight prior to flight.

Some airplanes are designed so that it is difficult to load them in a manner that will place the CG out of limits. These are usually small airplanes with the seats, fuel, and baggage areas located near the CG limit. These airplanes, however, can be overloaded in weight.

Other airplanes can be loaded in such a manner that they will be out of CG limits even though the useful load has not been exceeded.

Because of the effects of an out-of-balance or overweight condition, a pilot should always be sure that an airplane is properly loaded.


It might be advantageous at this point to review and discuss some of the basic principles of how weight and balance can be determined. The following method of computation can be applied to any object or vehicle where weight and balance information is essential; but to fulfill the purpose of this handbook, it is directed primarily toward the airplane.

By determining the weight of the empty airplane and adding the weight of everything loaded on the airplane, a total weight can be determined. This is quite simple; but to distribute this weight in such a manner that the entire mass of the loaded airplane is balanced around a point (CG), which must be located within specified limits, presents a greater problem, particularly if the basic principles of weight and balance are not understood.

The point where the airplane will balance can be determined by locating the center of gravity, which is as stated in the definition of terms, the imaginary point where all the weight is concentrated. To provide the necessary balance between longitudinal stability and elevator control, the center of gravity is usually located slightly forward of the center of lift. This loading condition causes a nose-down tendency in flight, which is desirable during flight at a high angle of attack and slow speeds.

A safe zone within which the balance point (CG) must fall is called the CG range. The extremities of the range are called the forward CG limits and aft CG limits.

These limits are usually specified in inches, along the longitudinal axis of the airplane, measured from a datum reference. The datum is an arbitrary point, established by airplane designers, which may vary in location between different airplanes.

The distance from the datum to any component part of the airplane, or any object loaded on the airplane, is called the arm. When the object or component is located aft of the datum, it is measured in positive inches; if located forward of the datum, it is measured as negative inches, or minus inches. The location of the object or part is often referred to as the station. If the distance from the datum (arm) multiplies the weight of any object or component, the product is the moment. The moment is the measurement of the gravitational force that causes a tendency of the weight to rotate about a point or axis and is expressed in pound-inches.

To illustrate, assume a weight of 50 pounds is placed on the board at a station or point 100 inches from the datum. The downward force of the weight can be determined by multiplying 50 pounds by 100 inches, which produces a moment of 5,000 lb-in.

To establish a balance, a total of 5,000 lb-in must be applied to the other end of the board. Any combination of weight and distance which, when multiplied, produces a 5,000 lb-in moment will balance the board.


Weight and balance control should be a matter of concern to all pilots. The pilot has control over loading and fuel management (the two variable factors that can change both total weight and CG location) of a particular airplane.

The airplane owner or operator should make certain that up-to-date information is available in the airplane for the pilot's use, and should ensure that appropriate entries are made in the airplane records when repairs or modifications have been accomplished. Weight changes must be accounted for and the proper notations made in weight and balance records. The equipment list must be updated, if appropriate. Without such information, the pilot has no foundation upon which to base the necessary calculations and decisions.

Before any flight, the pilot should determine the weight and balance condition of the airplane. Airplane manufacturers for the determination of loading conditions have devised simple and orderly procedures, based on sound principles. The pilot must use these procedures and exercise good judgment. In many modern airplanes, it is not possible to fill all seats, baggage compartments, and fuel tanks, and still remain within the approved weight and balance limits.

If the maximum passenger load is carried, the pilot must often reduce the fuel load or reduce the amount of baggage.


The pilot should be familiar with terms used in working the problems related to weight and balance. The following list of terms and their definitions is well standardized, and knowledge of these terms will aid the pilot to better understand weight and balance calculations of any airplane. Terms defined by the General Aviation Manufacturers Association as an industry standard are marked in the titles with GAMA.
  • Arm (moment arm)is the horizontal distance in inches from the reference datum line to the center of gravity of an item. The algebraic sign is plus (+) if measured aft of the datum, and minus (–) if measured forward of the datum.
  • Basic empty weight (GAMA)—includes the standard empty weight plus optional and special equipment that has been installed.
  • Center of gravity (CG)is the point about which an airplane would balance if it were possible to suspend it at that point. It is the mass center of the airplane, or the theoretical point at which the entire weight of the airplane is assumed to be concentrated. It may be expressed in inches from the reference datum, or in percent of mean aerodynamic chord (MAC).
  • Center-of-gravity limits—is the specified forward and aft points within which the CG must be located during flight. These limits are indicated on pertinent airplane specifications.
  • Center-of-gravity range—is the distance between the forward and aft CG limits indicated on pertinent airplane specifications.
  • Datum (reference datum)—is an imaginary vertical plane or line from which all measurements of arm are taken. The manufacturer establishes the datum. Once the datum has been selected, all moment arms and the location of CG range are measured from this point.
  • Delta—is a Greek letter expressed by the symbol �to indicate a change of values. As an example, �CG indicates a change (or movement) of the CG.
  • Floor load limit—is the maximum weight the floor can sustain per square inch/foot as provided by the manufacturer.
  • Fuel load—is the expendable part of the load of the airplane. It includes only usable fuel, not fuel required to fill the lines or that which remains trapped in the tank sumps.
  • Licensed empty weight—is the empty weight that consists of the airframe, engine(s), unusable fuel, and undrainable oil plus standard and optional equipment as specified in the equipment list. Some manufacturers used this term prior to GAMA standardization.
  • Maximum landing weight—is the greatest weight that an airplane normally is allowed to have at landing.
  • Maximum ramp weight—is the total weight of a loaded aircraft, and includes all fuel. It is greater than the takeoff weight due to the fuel that will be burned during the taxi and runup operations. Ramp weight may also be referred to as taxi weight.
  • Maximum takeoff weight—is the maximum allowable weight for takeoff.
  • Maximum weight—is the maximum authorized weight of the aircraft and all of its equipment as specified in the Type Certificate Data Sheets (TCDS) for the aircraft.
  • Maximum zero fuel weight (GAMA)—is the maximum weight, exclusive of usable fuel.
  • Mean aerodynamic chord (MAC)—is the average distance from the leading edge to the trailing edge of the wing.
  • Moment—is the product of the weight of an item multiplied by its arm. Moments are expressed in pound-inches (lb-in). Total moment is the weight of the airplane multiplied by the distance between the datum and the CG.
  • Moment index (or index)—is a moment divided by a constant such as 100, 1,000, or 10,000. The purpose of using a moment index is to simplify weight and balance computations of airplanes where heavy items and long arms result in large, unmanageable numbers.
  • Payload (GAMA)—is the weight of occupants, cargo, and baggage.
  • Standard empty weight (GAMA)—consists of the airframe, engines, and all items of operating equipment that have fixed locations and are permanently installed in the airplane; including fixed ballast, hydraulic fluid, unusable fuel, and full engine oil.
  • Standard weights—have been established for numerous items involved in weight and balance computations. These weights should not be used if actual weights are available. Some of the standard weights are:
    • Gasoline . . . . . . . . . . . . . . . . . . . . . 6 lb/US gal
    • Jet A, Jet A-1 . . . . . . . . . . . . . . . . 6.8 lb/US gal
    • Jet B . . . . . . . . . . . . . . . . . . . . . . . 6.5 lb/US gal
    • Oil . . . . . . . . . . . . . . . . . . . . . . . . 7.5 lb/US gal
    • Water . . . . . . . . . . . . . . . . . . . . . 8.35 lb/US gal

    • Station—is a location in the airplane that is identified by a number designating its distance in inches from the datum. The datum is, therefore, identified as station zero. An item located at station +50 would have an arm of 50 inches.
    • Useful load—is the weight of the pilot, copilot, passengers, baggage, usable fuel, and drainable oil. It is the basic empty weight subtracted from the maximum allowable gross weight. This term applies to general aviation aircraft only.

NZ Civil Aircraft

NZ Civil Aircraft blog.

What a splendid idea !

I look forward to offering my observations and comments on a casual basis.

I also await with interest other NZ Civil Aircraft enthusiests sightings and offerings to this new blog.

I am Christchurch based and prefer the lighter side of aviation, especially helicopters and gliders, although I follow the NZ civil register with considerable interest.

Blue Bus


Adverse balance conditions affect airplane flight characteristics in much the same manner as those mentioned for an excess weight condition. In addition, there are two essential airplane characteristics that may be seriously affected by improper balance; these are stability and control. Loading in a nose-heavy condition causes problems in controlling and raising the nose, especially during takeoff and landing. Loading in a tail-heavy condition has a most serious effect upon longitudinal stability, and can reduce the airplane's capability to recover from stalls and spins. Another undesirable characteristic produced from tail-heavy loading is that it produces very light control forces. This makes it easy for the pilot to inadvertently overstress the airplane.

The manufacturer establishes limits for the location of the airplane's center of gravity. These are the fore and aft limits beyond which the CG should not be located for flight. These limits are published for each airplane in the Type Certificate Data Sheet, or Aircraft Specification and the Airplane Flight Manual or Pilot's

Operating Handbook (AFM/POH). If, after loading, the CG is not within the allowable limits, it will be necessary to relocate some items within the airplane before flight is attempted.

The forward center-of-gravity limit is often established at a location that is determined by the landing characteristics of the airplane. During landing, which is one of the most critical phases of flight, exceeding the forward CG limit may result in excessive loads on the nosewheel; a tendency to nose over on tailwheeltype airplanes; decreased performance; higher stalling speeds; and higher control forces. In extreme cases, a CG location that is forward of the forward limit may result in nose heaviness to the extent that it may be difficult or impossible to flare for landing.

Manufacturers purposely place the forward CG limit as far rearward as possible to aid pilots in avoiding damage to the airplane when landing. In addition to decreased static and dynamic longitudinal stability, other undesirable effects caused by a CG location aft of the allowable range may include extreme control difficulty, violent stall characteristics, and very light stick forces that make it easy to overstress the airplane inadvertently.

A restricted forward center-of-gravity limit is also specified to assure that sufficient elevator deflection is available at minimum airspeed. When structural limitations or large stick forces do not limit the forward CG position, it is located at the position where full-up elevator is required to obtain a high angle of attack for landing.

The aft center-of-gravity limit is the most rearward position at which the CG can be located for the most critical maneuver or operation. As the CG moves aft, a less stable condition occurs, which decreases the ability of the airplane to right itself after maneuvering or turbulence.

For some airplanes the CG limits, both fore and aft, may be specified to vary as gross weight changes. They may also be changed for certain operations such as acrobatic flight, retraction of the landing gear, or the installation of special loads and devices that change the flight characteristics.

The actual location of the CG can be altered by many variable factors and is usually controlled by the pilot.

Placement of baggage and cargo items determines the CG location. The assignment of seats to passengers can also be used as a means of obtaining a favorable balance. If the airplane is tail-heavy, it is only logical to place heavy passengers in forward seats. Also, fuel burn can affect the CG based on the location of the fuel tanks.


Balance refers to the location of the center of gravity (CG) of an airplane, and is important to airplane stability and safety in flight. The center of gravity is a point at which an airplane would balance if it were suspended at that point.

The prime concern of airplane balancing is the fore and aft location of the CG along the longitudinal axis.

The center of gravity is not necessarily a fixed point; its location depends on the distribution of weight in the airplane. As variable load items are shifted or expended, there is a resultant shift in CG location. The pilot should realize that if the CG of an airplane is displaced too far forward on the longitudinal axis, a nose-heavy condition will result. Conversely, if the CG is displaced too far aft on the longitudinal axis, a tail-heavy condition will result. It is possible that an unfavorable location of the CG could produce such an unstable condition that the pilot could not control the airplane.

Location of the CG with reference to the lateral axis is also important. For each item of weight existing to the left of the fuselage centerline, there is an equal weight existing at a corresponding location on the right. This may be upset, however, by unbalanced lateral loading.

The position of the lateral CG is not computed, but the pilot must be aware that adverse effects will certainly arise as a result of a laterally unbalanced condition.

Lateral unbalance will occur if the fuel load is mismanaged by supplying the engine(s) unevenly from tanks on one side of the airplane. The pilot can compensate for the resulting wing-heavy condition by adjusting the aileron trim tab or by holding a constant aileron control pressure. However, these places the airplane controls in an out-of-streamline condition, increases drag, and results in decreased operating efficiency. Since lateral balance is relatively easy to control and longitudinal balance is more critical, further reference to balance in this handbook will mean longitudinal location of the center of gravity.

In any event, flying an airplane that is out of balance can produce increased pilot fatigue with obvious effects on the safety and efficiency of flight. The pilot's natural correction for longitudinal unbalance is a change of trim to remove the excessive control pressure.

Excessive trim, however, has the effect of not only reducing aerodynamic efficiency but also reducing primary control travel distance in the direction the trim is applied.


Altering the fuel load can change the weight of the airplane. Gasoline has considerable weight—6 pounds per gallon—30 gallons may weigh more than one passenger. But it must be remembered that if reducing fuel lowers weight, the range of the airplane is decreased. During flight, fuel burn is normally the only weight change that takes place. As fuel is used, the airplane becomes lighter and performance is improved.

Changes of fixed equipment have a major effect upon the weight of the airplane. An airplane can be overloaded by the installation of extra radios or instruments.

Repairs or modifications may also affect the weight of the airplane.


Hello, my name is Karoliina Salminen and the intention of this blog is to follow topics related to light aircraft design. I do have a dream and want to share it with you.

Blog Archive
